Capacity
								2TB | 1TB | 500GB

														-

Form Factor
								M.2 2280

														-

Interface
								PCIe 3.0

														-

Performance
								Sequential Read/Write:
500GB: up to 3300MB/s read, up to 1700MB/s write speeds
1TB: up to 3300MB/s read, up to 2600MB/s write speeds
2TB: up to 3300MB/s read, up to 2600MB/s write speeds

														-

Total Bytes Written
								500GB: 120TBW
1TB: 240TBW
2TB: 480TBW

														-

Operating Temperature
								0° to 70° C (32°F to 158°F)

														-

Storage Temperature
								-40° to 85° C (-40°F to 185°F

														-

Shock Resistant
								1500G, duration 0.5ms, Half Sine Wave3

														-

Vibration Resistant
								10~2000Hz, 1.5mm, 20G, 1 Oct/min, 30min/axis (X,Y,Z)3

														-

DWPD
								0.535

														-

MTBF
								1,500,000 Hours

														-

Dimensions
								80 x 22 x 2.45mm / 3.15”x0.87”x0.10” (with front label)

														-

Warranty
								3-year limited warranty



						1Up to 3300MB/s read transfer, write transfer speeds lower. Speeds based on internal testing. Actual performance may vary.
2Shock resistant (1500G, duration 0.5ms, Half Sine Wave) and vibration resistant (10~2000Hz, 1.5mm, 20G, 1 Oct/min, 30min/axis(X,Y,Z)). Based on internal testing. Actual performance may vary.
3Comparison based on internal testing. Actual performance may vary.
Security safeguards, by their nature, are capable of circumvention. Lexar does not guarantee data will be 100% secure from unauthorized access, alteration, or destruction.
Lexar is not liable for any loss of data or images.
General Disclosure
Product appearance, performance, software, and packaging may vary based on shipping date and available inventory.
Usable Storage Disclosure
Actual usable storage may be less than stated due to system formatting and other functions. 1GB = 1 billion bytes.
